guest
Re :   Tele Project

You know, that thing looks great! Glad you stuck with single coil looks!


11/10/2009 17:28:54


guest
Topic :   tele nashville power

Does anyone know what kind of tone pot is used on a Nashville power tele? 250k or 500kWould also appreciate any knowledge any of you might have about modding these teles with the piezzo bridge pickups and smart chip circuit.One last thing... any suggestionns on strings?  I have been using Fender 150Ms but the unwound sound too bright and the wound three sound a bit too mellow... sometimes it seems like I am playing two different guitars... and not because of the stereo circuitry!


11/08/2009 09:04:54


asiegler
Re :   Classic 57 in Tele Thinline

Just got my pickups in.  Working on fine tuning the pickups/setup.  Trying to upload some pictures but running into trouble trying to post JPG files.  Any help?.




11/06/2009 10:41:31


asiegler
Re :   Classic 57 in Tele Thinline

 Finally got my special order pickguard.  Plan on putting it all together in coming week.  Will post pictures of the finish product.




11/01/2009 16:23:14


Dandy_Coba
Re :   TrussartyCaster

Have now finished the project, and photos can be seen at http://zone.aimoo.com/photo/Dandy_Cobalt   Everything worked out really weel, and after settting up the guitar it plays wonderfully. Hope you like the pictures.

I'm now working on a new project, combining a reliced body and parts from MJT guitars (you can find them on ebay) - a nitro reliced black finish, putting the mex neck from the Fender, plus the original pickups, but using a four-way selector and control panel that I picked up from ebay supplier.


10/30/2009 05:55:11


guest
Re :   2 volume 1 tone - where to mount tone knob?

 use a 72 re-issue set up with 2 volumes & 2 tones.  then a coil splitting mini switch.


10/29/2009 15:23:37


guest
Re :   Mini Humbucker Body Mod

 on another part of this site, a guy said he used a 1971 gibson mini humbucker from a les paul classic & no changes had to be made for the body or the pick guard. i've not tried it so i can't say for sure. check the new hot rod 52 tele with a mini hum in the neck.
i've seen the holes in these guitars bashed out with a hammer & screw driver etc. these are the wrong tools. if you don't have a router to do it ...... get one or have it done.
i just got a 72 re-issue. hum neck single bridge. neck was too muddy & bridge was so thin it hurt your ears. instead of a major change i read to change the 250 k pots on the neck to a 500k pot. this worked. plus changing to a better capacitor on the neck & the bridge. a good guitar tech knows what to use & how to do it. visit your local shops where they know how & can help. $31 to change caps & pots & fix a not so great sounding MIM to a good sounding playable guitar. now that's cheap. the mini hum for the 52 hot rod is around $100. have it put in & change the pots & caps at the same time.


10/29/2009 15:16:25


guest
Re :   Has anyone ever used a tele neck on a strat?

 answer.... YES . i think it was jimi Hendrix


10/29/2009 14:56:10


guest
Re :   Neck humbucker question

 a balance can be done to an extent by only lowering the neck & raising the bridge pickup. use the screws to do it. keep going til you get a more balanced volume. changing a single coil to a hum needs the changing of the pots to a 500k instead of a 250 k. or you get a muddy tone. 500k's on the humbuckers open up the highs.


10/29/2009 14:52:07


Deke Marti
Re :   My latest Tele project

Thanks guys.  Hwunch, they're standard Gretsch White Falcon knobs.  I figured with the red jewel and white MOP dot in the middle pretty much obscuring the G it would be OK.

The pick-ups are a TV Classic in the bridge (about the change though, watch this space), and a TV Jones P90 in the neck.

Sounds awesome.


10/24/2009 05:58:28


asiegler


10/23/2009 10:32:08


asiegler
Topic :   Classic 57 in Tele Thinline

Anybody thought about putting Gibson's Classic 57 and Classic 57 plus pickups in a MIM 72 Tele Thinline guitar?  Currently working on this project.


10/23/2009 10:29:56


dennistruc
Topic :   Fake 'Relics' on eBay....

http://cgi.ebay.com/Fender-American-Deluxe-Telecaster-Relic_W0QQitemZ220496723116QQcmdZViewItemQQptZGuitar?hash=item3356a0fcac

http://cgi.ebay.com/Fender-Stratocaster-RELICd_W0QQitemZ220496727138QQcmdZViewItemQQptZGuitar?hash=item3356a10c62


10/22/2009 17:10:12


hwunch
Re :   My latest Tele project

 she is purdy! Can you get a pic on the detail on the knobs? I would love a better look at those.


10/19/2009 08:46:29


guest
Re :   TrussartyCaster

Just received the Indian Rosewood (front and back) neck from Warmoth - absolutely beautiful, and profile is exactly what I was looking for !!! It is almost identical in figuring on the fingerboard to the Trussart Rust-o-matic Star guitar that we are trying to mimic. http://www.jamestrussart.com/Guitar-Stock-Photos/Steelcaster/09134/Large/DSC_6679%20copy.JPG

Great service from Warmoth, by the way.

The neck has been given to the chap doing the custom paint job. He won't let me see the body whilst painting, as he says he has already taken a chisel to it and I may grab the guitar and run to the nearest bridge to jump off. So sorry no pics so far.

The bridge arrived, via ebay and has been electrolysed - worked really well. As did the control plate - we've decided to keep the original flat Fender one but the electrolysis has changed it beyond recognition - looks lovely and rusty now.

I used bleach on the brass saddles, but haven't greened in the way I would like - maybe good honest playing sweat will be the answer to that one?



10/15/2009 07:26:22


guest
Re :   Gibson Melody Maker to Flying V Conversion

i have a gibson worn cherry flying v. i fell in love with it from the start. sad to say she's acting up and not staying in tune to well. i had it set up a couple months ago and it was doing great until recently. any suggestions about upgrades for the machineheads or anything else. would appreciate any feedback


10/14/2009 08:56:20


jgerards
Topic :   Need help with wiring a rotary switch!

Hey guys,


I have a guitar I'm building with 2 lindy fralin P-92 single coil pickups.  I have a 4-pole 5-position rotary switch that I would like to use as the pickup selector.  I've seen lots of wiring diagrams for rotary switches, but the problem is that they all seem to be for "4-wire" humbuckers.  Does anyone know where I can find a wiring layout for using a 5-way rotary with single coil pickups?  Any feedback is appreciated.  Thanks!!


Jeff


10/10/2009 11:20:33


Dandy_Coba
Topic :   TrussartyCaster

Hi all, I'm a new member and have just started to customise my Fender Mexican Telecaster.

I have always wanted a Trussart, but way short of the $4,500 I needed.

As I also play in a Southern Rock band here in the UK, I also wanted something with a bit of southern-style.

So, first step was to get the right sound - I've installed BareKnuckle "Boss" pickups and a four-way selector switch - fantastic boost in the fourth position - I can almost compete with the two Les Pauls and Marshall stacks in the band:-)

Next step - I'm using aluminium flooring ( like another mod in the gallery by Glyn in Wales) but I'm only mimicking the scratchplate and control panel, so no work needed to the actual body size/shape.

eventually, a local artist is going to airbrush the body to make it look rusty, hit by a truck dirty, with a star from the confederate flag overlapping the nexk pickup. To make the paint stick, we've done a first step of etching the aluminium with drain cleaner (sodium hydroxide mainly). The oxide formed gives the metal a dull white look, but hopefully the paint should stick. Ditto with a control panel that I've made copying the original shape.

I've ordered a Wilkinson 3-brass saddle chrome bridge, and am going to use electrolysis to age the chrome, and bleach to age the brass saddles. At this point, any comments/hints are gratefully appreciated!!!!

I've also ordered a replacement neck from Warmoth - Indian rosewood and a "flame" in it that also looks like rust, which should complement the bodywork and play better than the original mex neck (I've also gone for jumbo frets like a great '77 Deluxe that I also own)

Finally, the tuners will get the electrolysis treatment on the knob-bits.

Any suggestions for a metal partial cover for the headstock most welcome - have tried Glyn by email but bounced back - though he might have a few spares in the garage:-)

I'll post photos soon, as the project starts to take shape.







10/06/2009 10:43:06


RoadConePr
Topic :   Build your own Pickups

I am attempting to build my own pickups by hand. First i was wondering if anyone here has done this, how they turned out, and where they got their components. I know that they are easy to assemble frame + magnets + thousands of turns thing gauge copper wire. the thinner the wire plus an increase in the number of turns equals a hotter pickup. I just have no clue how to go about getting the materials. any help would be greatly appreciated. i am also looking to find better built components for the inner wiring of my MIM tele. what would a 125K ohm tapper pot do vs the standard 250k tapper pot. would this create a higher out put seeing as there is less resistane or would this just generate more hum. I am ultimatly trying to build a one of a kind high output noise free tele.


10/01/2009 10:23:13


Deke Marti
Topic :   My latest Tele project

Well guys and girls, it's been ages since I was here, but I thought you might like to see this:



Ain't she purdy?


09/29/2009 10:25:34


jgerards
Topic :   Rotary Switch as pickup selector?

Hey guys,
So here's the scenario... I am doing the electronic work on a guitar my buddy is making.  The body is a tele style, but it is a drop top with no pick guard or metal control plate.  So we are drilling into the wood and using longer shafted pots and a les paul style toggle switch for the pickup selector.  However, what I would like to do is have a selector switch that could do 4 or 5 positions for different pickup configurations, but I can't use the standard tele/strat style "lever" switches because I can't cut into the wood like that without it splitting.

Question:  Can I use a rotary switch as a pickup selector?  I was thinking like  2 pole, 4-5 position rotary.  Would that work with just 2 poles for each position?

Thanks in advance for any advice!



Jeff


09/22/2009 12:58:25


guest
Re :   'undrilled' Tele control plates?

Taipan Tone Engineering has several specialized Telecaster control plates, including a standard Telecaster plate with an angled switch slot and a plate with three holes that's designed for volume, tone and an LP toggle switch.  This site's worth checking out.  I'm fascinated by the Taipantone ferrule bar as well......trying one on my next Thinline build.


09/20/2009 21:58:10


chuckocast
Re :   Nashville Tele Wiring Mod

 the way easy mod is to swap the middle bridge leads going into the switch so you get n, n/b, b, b/m, m. or you can swap the middle and neck leads and get m, m/n, n, n/b, b. or if you want to get fancy you can put a 3 way standard switch with a push pull pot. that way you can combine the middle with any position.


08/28/2009 02:35:13


guest
Re :   I need a left handed Bigsby B5 kit for my Telecaster




Alright i'm thinking of putting a bigsby on my telecaster, how did you get on?


08/26/2009 06:02:01


devils_too


08/24/2009 17:19:39


guest
Re :   Nashville Tele Wiring Mod

Also look up the Nashville B-Bender diagrams on Fender.  The new ones are
N
N+M
N+B
M+B
B
That is how mine was a standard


08/18/2009 07:32:29


Natsteel
Re :   Bigsby Palm Pedal?

 you can get them from Dan Balde at http://www.bigsbypalmpedals.com/


08/16/2009 03:46:44


JETIII
Topic :   Suggestions as to Pickups

I have a sunburst pair (1998 and a 1999) of American Standard Telecasters  - I wish to keep the 1998 pretty much stock and want to buy a set of terrific pickups for the 1999 for hard Rock, metal shredding etc. without destroying the guitars vintage good looks and aesthetics, any qualified suggestions? Let me know if the pots will need to be changed too!



08/14/2009 14:22:49


devils_too
Topic :   WTB: Ibanez Iceman ICJ100WZ - White Zombie Model

Howdy all - just thought I'd check in. Haven't snooped here in a while and I'm on the hunt for a guitar. The elusive Ibanez White Zombie Iceman - ICJ100WZ.

It's a purty little beast (I think):



Do you know anybody trying to unload one?

Point them my way.

Thanks!


08/04/2009 17:58:23


guest
Topic :   Nashville Tele Wiring Mod

I'd like to rewire my nashville tele so that I can get the typical bridge/neck pup combination when I set the 5-way switch in the middle (#3?) position.  As it is now, only the middle pup is active in that position.  How would I rewire this?Also, can anyone point me to some sort of explanation or diagram of how the 5-way switch works?  i.e. what lugs are connected to each other in each switch position.thanks!


08/03/2009 17:26:41
